Zu20

Short Description:

JAKA Cobot ZU20 Payload 20kg Arm reach 1780mm...


  • Brand: JAKA
  • Model: Zu20
  • Payload: 20kg
  • Arm Reach: 1780mm
  • Accuracy: ±0.05mm
  • Controlled Axes: 6
  • Weight: 68kg
  • Payment: T/T
  • Lead Time: 2-4weeks

Product Detail

Product Tags

JAKA Zu20

Payload: 20 kg, Weight: 68 kg, Reach: 1780 mm

This is a new collaborative robot specifically designed for high-load, large-radius applications. It inherits numerous technical advantages from the JAKA Zu series, including ease of use, safety, reliability, and high precision. With a 1780 mm reach, 20 kg payload capacity, and IP65 protection rating, it expands application possibilities, providing solutions for processing, handling, welding, bonding, palletizing, and packaging of heavy and large workpieces.
