Zu12

Short Description:

JAKA Cobot ZU12 Payload 12kg Arm reach 1327mm...


  • Brand: JAKA
  • Model: Zu12
  • Payload: 12kg
  • Arm Reach: 1327mm
  • Accuracy: ±0.03mm
  • Controlled Axes: 6
  • Weight: 41kg
  • Payment: T/T
  • Lead Time: 2-4weeks

Product Detail

Product Tags

JAKA Zu12

Payload: 12 kg, Weight: 41 kg, Reach: 1327 mm

Human-Machine-Environment Collaborative Integration Payload: 12 kg, Self-Weight: 41 kg, Reach: 1327 mm Integrated joint design for easy assembly and disassembly Higher payload capacity and extended reach enable handling of heavy physical tasks Adhering to the principle of “Human-Machine-Environment Collaborative Integration,” the high-safety design eliminates the need for isolation barriers.
