Class-leading performance for high-quality manufacturing

Aimed at increasing manufacturing productivity, IRB 1100 provides up to 35% faster cycle times and best-in-class repeatability for high quality manufacturing. IRB 1100 consistently outperforms similar robots in terms of payload and position repeatability (RP) even when under space constraints. Indeed, IRB 1100 offers the highest payload for a robot of its class. Compared to the previous generation, the IRB 1100 robot design was optimized with a 10% smaller footprint and over 20% weight reduction for space-efficient installation in diverse environments, such as electronics manufacturing factories. The IRB 1100 is powered by OmniCore E10 ultra-slim, C30 compact, and C90XT rugged compact controllers.

Key benefits

·Offers 35%faster cycle times forincreased productivity

·10%smaller footprint and over 20% weight reduction for easy installation

·The highest payload for a robot of its class

·Equipped with up to 161/O connections(C1+C2)for more sophisticated/complex applications

Main applications

·Assembly &Testing

·Loading &Unloading

·Screw driving

·Rubberinsertion

·Polishing,grinding,buffing,deburring and sanding
